Model No: AT070TN94
Brand: Innolux
LCD Size: 7 inch
Aspect Ratio: 16:9
Touch: No
Driver element: a-Si TFT active matrix
Relosution: 800x480
Brightness: 400cd/m2
Viewing angle: 6 o’clock
Color:262K
Display Mode: Normally White, Transmissive
Active area: 154.08(W)x85.92(H)mm
Module Size: 164.9(W)x100(H)x5.7(D)mm
Interface: TTL
Working Temp.: -30 ~ 85 °C
Storage Temp.: -30 ~ 85 °C
Lifetime:20K(min.)
Packing: 50 pcs/ctn, 10.68±0.52 Kgs, 530x355x255 mm (L×W×H)
Drawing:
Application:
Medical Equipment,Industrial Equipoment,Car GPS Navigators,Printer,Elevatordisplay etc...
